Note: Diptera larvae may live in a corridor mine, a corridor-blotch mine, or a blotch mine, but never in a case, a rolled or folded leaf, a tentiform mine or sandwiched between two more or less circular leaf sections in later instars. Pupation never in a cocoon. All mining Diptera larvae are leg-less maggots without a head capsule (see examples). They never have thoracic or abdominal legs. They do not have chewing mouthparts, although they do have a characteristic cephalo-pharyngeal skeleton (see examples), usually visible internally through the body wall. The larvae lie on their sides within the mine and use their pick-like mouthparts to feed on plant tissue. In some corridor miners frass may lie in two rows on alternate sides of the mine. In order to vacate the mine the fully grown larva cuts an exit slit, which is usually semi-circular (see Liriomyza huidobrensis video). The pupa is formed within the hardened last larval skin or puparium and as a result sheaths enclosing head appendages, wings and legs are not visible externally (see examples).

1a > Blotch mine. Pupation external. Puparium yellow

On numerous genera of Asteraceae in Britain and elsewhere. In Britain more common in the north than in the south. Also throughout the Palaearctic Region except the Mediterranean and Middle Eastern areas.

Trypeta artemisiae (Fabricius, 1794) [Diptera: Tephritidae].

1b > Corridor mine.

2

2a > Corridor mine primarily associated with the mid-rib.

3

2b > Corridor mine not primarily associated with the mid-rib.

4

3a > Corridor mine following the mid-rib, with lateral offshoots. Puparium yellow

On numerous genera of Asteraceae. Throughout the British Isles, more common in the south than the north. Also continental Europe.

Trypeta zoe Meigen, 1826 [Diptera: Tephritidae].

3b > Leaf-miner: A distinctive mine primarily above mid-rib, with irregular short lateral offshoots into leaf blade. Pupation external (Spencer, 1972: 51 (fig. 172), 55; Spencer, 1976: 270, 271 (fig. 486)). Branched, whitish, upper-surface corridor; main axis overlying the midrib; side branches overlying the main lateral veins. (In Campanula and Phyteuma the mine is much less branched, sometimes nothing more than a corridor on top of the midrib). Frass in rather long strings. Usually the mines begins as a long and narrow, shallow, tortuous lower-surface corridor that ends upon the midrib but otherwise is not associated with the leaf venation. Often this initial corridor is filled with callus, and then even less conspicuous. Pupation outside the mine (Bladmineerders van Europa). A linear mine on the upper surface, usually following the midrib and showing side branches along the veins. The frass is in strings (British leafminers).

On more than 40 host genera in 15 families in Britain including Tanacetum. Widespread throughout Britain. Also recorded in the Republic of Ireland. Widespread in continental Europe.

Liriomyza strigata (Meigen, 1830) [Diptera: Agromyzidae]

4a > Leaf-miner: Mine linear, whitish, both upper and lower surface. Pupation internal, at the end of the mine with the anterior spiracles projecting through the epidermis (Spencer, 1976: 433). Upper-surface, less often lower-surface corridor. Frass in isolated grains. Pupation within the mine, in a, usually lower-surface, pupal chamber (Bladmineerders van Europa). A long whitish upper surface corridor, which eventually goes lower surface (British leafminers).

Two highly polyphagous species of Chromatomyia, with indistinguishable mines, have been recorded in Britain. These are syngenesiae (Hardy) and horticola (Goureau) which can only be distinguished by the male genitalia. Both are polyphagous and widespread in Britain and elsewhere, although syngenesiae is almost entirely restricted to Asteraceae (see also 'atricornis').

Chromatomyia horticola is recorded on 55 plant genera in 19 families in Britain but not yet on Tanacetum in Britain.

Chromatomya syngenesiae is recorded in Britain on 27 plant genera in the family Asteraceae and many more genera elsewhere, including Tanacetum in Britain.

Chromatomyia 'atricornis' has been recorded on Tanacetum in Britain.

Chromatomyia horticola (Goureau, 1851) [Diptera: Agromyzidae].
OR
Chromatomyia syngenesiae Hardy, 1849 [Diptera: Agromyzidae].

4b > A narrow linear mine, with frass in black strips. Puparium yellowish-black

Mine of Liriomyza tanaceti on Tanacetum vulgare Image: Willem Ellis (Bladmineerders van Europa)

On Artemisia, Chrysanthemum and Tanacetum in Britain and Tanacetum elsewhere. Known only from Surrey and Warwick in Britain. Widespread and not uncommon in much of western Europe

Liriomyza tanaceti Meijere, 1924 [Diptera: Agromyzidae].

4c > Leaf-miner: A narrow linear mine, even in the finest subdivisions of the leaves (Spencer, 1972: 77, as matricariae; Spencer, 1976: 478). Very fine corridor, upper- or lower-surface, even in the narrowest leaf segments. The corridor may be up to 14 cm long (Sehgal, 1971a). Generally the corridor descends towards the leaf base. Frass in pearl chains of loose grains, hardly in strings. Pupation outside the mine (Bladmineerders van Europa). Pupal posterior spiracles each with 18-20 bulbs.

On Achillea millefolium, Anacyclus pyrethrum, Anthemis, Tanacetum vulgare, Tripleurospermum, Tripleurospermum maritimum and Tripleurospermum maritimum x inodora in Britain and other Asteraceae elsewhere. Widespread in Britain and continental Europe. Also recorded in Canada.

Phytomyza pullula Zetterstedt, 1848 [Diptera: Agromyzidae].

4d > A linear mine, frequently on lower surface at beginning; frass with closely adjoining grains. Puparium black

On Tanacetum in Britain. On Achillea, Leucanthemum, Pyrethrum and Tanacetum elsewhere. Probably widespread in Britain, recorded only in Surrey and Warwick. Widespread in continental Europe.

Phytomyza tanaceti Hendel, 1923 [Diptera: Agromyzidae].
